ONLINE UPS LXi990 Z5 – Lifetronics
Applications
- Hospitals & Healthcare – MRI, CT scanners, ICU, operating theatres.
- Data Centers – Servers, cloud storage, IT infrastructure.
- Industrial Units – CNC, robotics, PLCs, automation systems.
- Telecom & Defense – Base stations, radar, command centers.
- Corporate & Government – Banks, financial institutions, control rooms.
Technical Specifications
Input Voltage: 380/400/415V (3-Phase)
Frequency: 50/60Hz auto-sensing
Efficiency: 95% Online Mode, 98% ECO Mode
Output Voltage: 380/400/415V ±1%
Output Waveform: Pure Sine Wave
Overload Capacity: 125% – 150% (long-term & short bursts)
Battery System: 192V DC, configurable (32–40 pcs)
Charging Current: 10A/15A/20A (depending on model)
THDi: <3%
Cooling: Intelligent forced-air cooling
Protection: Short-circuit, overload, overtemperature, undervoltage, battery failure
Key Features
True Online Double Conversion with full DSP digital control.
Output Power Factor 1.0 – Maximum active power support.
High Efficiency – 95% in online mode, up to 98% in ECO mode.
Active Power Factor Correction (APFC) – Input PF ≥ 0.99.
Wide Input Voltage Range (304–478 VAC) for harsh grid conditions.
Zero Transfer Time – Seamless power supply during mains failure.
Flexible Battery Configuration – 32 to 40 batteries selectable.
Intelligent Battery Management – Equalized & float charging, dormancy control, longer life.
Cold Start Function – Start UPS directly from battery when mains power is unavailable.
Dual Input Design – Independent bypass support.
Advanced Protection – Against surge, short-circuit, overvoltage, undervoltage, and overload.
Smart Cooling – Intelligent fan speed adjustment reduces noise & extends life.
User-Friendly Interface – 5” LCD color touchscreen with real-time monitoring.
Multiple Communication Options – RS232, USB, RS485, SNMP, Wi-Fi, GPRS, Dry contacts.
Compact Design – Small footprint for easy installation.
Why Choose Lifetronics for LXi900 Z5?
Certified ISO 9001:2015 & CE compliant
Supply, installation & AMC across India, Asia, Africa & Europe
Technical expertise since 2007
Customized battery backup & UPS configurations available
Trusted by industries, hospitals, PSUs, and MNCs
