Online UPS LXi890B
Online UPS LXi890B
Online UPS LXi890B – Lifetronics
Applications of Electroplating Rectifiers
- Hospitals & Healthcare – life support, diagnostic & imaging systems
- Data Centers & IT – servers, telecom switching, cloud facilities
- Industrial Plants – automation, robotics, CNC, PLCs, process lines
- Commercial & Government – banking, telecom, research centers
- Defense & Labs – R&D testing, sensitive equipment backup
Models
- LXi8980 (80kVA/72kW)
- LXi89100 (100kVA/90kW)
- LXi89120 (120kVA/108kW)
- LXi89200 (200kVA/180kW)
- LXi89250 (250kVA/225kW)
- LXi89300 (300kVA/270kW)
- LXi89400 (400kVA/360kW)
- LXi89500 (500kVA/450kW)
Technical Specifications
Models: LXi8980 (80kVA/72kW), LXi89100 (100kVA/90kW), LXi89120 (120kVA/108kW), LXi89200 (200kVA/180kW), LXi89250 (250kVA/225kW), LXi89300 (300kVA/270kW), LXi89400 (400kVA/360kW), LXi89500 (500kVA/450kW)
Input:
3-Phase, 380/400/415 VAC
Voltage range: 304 – 346 V (derating load), 346 – 456 V (full load)
Frequency: 50/60 Hz ± 5 Hz
Input PF: >0.99 | THDi ≤3%
Output:
Voltage: 380/400/415 VAC
Regulation: ±1%
Waveform: Pure sine wave
Power Factor: 0.9
THDv: ≤2% (linear load), ≤5% (non-linear load)
Overload: 110% for 10 min, 125% for 1 min
Isolation: Output isolation transformer (DZnO winding for unbalanced loads)
Battery:
DC Voltage: 600V DC (Lead Acid) / 614.4V DC (Lithium-ion option)
Configurations: 12V × 50 pcs, 2V × 300 pcs, 3.2V × 192 pcs
Adjustable charging current (settable by battery capacity)
Efficiency:
Online mode: 92–94%
ECO mode: up to 98%
Display: 5.7” color LCD touchscreen with history logs
Parallel Redundancy: N+X up to 6 units
Key Features
DSP controlled, double conversion UPS for highest reliability
High input PF (>0.99) and low THDi (≤3%) → reduces grid stress
Output isolation transformer ensures full input/output separation
Strong mixed load & overload handling (unbalanced loads supported)
Compact footprint & unique ventilation design
Front accessible maintenance → easy service, wall-mount compatible
Generator compatible with stable operation
Intelligent self-diagnostics with event history & fault protection
Optional N+X redundancy → scalable up to 6 units
High MTBF (>200,000 hrs) and Low MTTR (<0.5 hr)
Why Choose Lifetronics for LXi890B UPS?
Certified to ISO & CE standards
Full range from 80kVA to 500kVA
Energy-efficient → reduces operating costs
Customizable battery backup (lead-acid & lithium)
Trusted by industries since 2007
Global export: India, Asia, Africa & Europe
Call +91 99984 31599 or services@lifetronics.org to get the best deals on Isolation Transformers for your industry, business, or hospital.
Since 2007, Lifetronics has delivered trusted industrial & medical electronics repair, UPS servicing, battery charger solutions, automation systems, and hospital equipment support across India, Asia, Africa & Europe.
