Online UPS LXi800 – Lifetronics
Applications of Electroplating Rectifiers
- Hospitals & Healthcare – diagnostic labs, MRI/CT, surgical equipment
- Data Centers & IT – servers, storage, networking
- Industrial Use – automation, CNC, PLCs, process control
- Commercial – offices, banks, telecom
- Research & Defense – labs, R&D testing facilities
Technical Specifications
Models: LXi810 (10kVA/8kW), LXi815 (15kVA/12kW), LXi820 (20kVA/16kW), LXi830 (30kVA/24kW)
Input Supply: 380/400/415 VAC, Three-phase, 50/60 Hz
Voltage Range: 285–475 VAC
Frequency Range: 40–70 Hz
Output Voltage: 220/230/240 VAC ±1%
Output Waveform: Pure Sine Wave
Power Factor: 0.8
THDv: ≤2% (linear load), ≤5% (non-linear load)
Overload Capacity: 125% for 10 min, 150% for 200 ms
Bypass: Automatic / Manual with DSP control
Battery Voltage: 192 VDC
Battery Configuration: 12V × 16 pcs
Charging Voltage: 216 VDC
Charging Current: 2A–12A (selectable), up to 24A optional
Efficiency: >94% (online), 98–99% (ECO mode)
Noise Level: <60 dB
Key Features
True Double Conversion – stable, uninterrupted power supply
DSP Technology – intelligent monitoring & control
Handles All Loads – resistive, inductive, and non-linear
High Overload Capacity – up to 150%
Parallel & Redundant Operation – scalable for higher loads
Dual Input & Hot Standby – maximum uptime
Cold Start & Mains Start – flexibility in any environment
Advanced Protection – surge, short circuit, overvoltage, undervoltage, overcharge
Communication Options – RS232, USB, SNMP, RS485, Wi-Fi (optional)
Built-in Output Isolation Transformer
Why Choose Lifetronics for LXi800 UPS?
ISO-certified quality systems
Models from 10kVA to 30kVA available
Customizable battery backup solutions
High efficiency with reduced operating costs
Nationwide support & international export (Asia, Africa, Europe)
Trusted by industries since 2007
