DSP Static Voltage Stabilizer – Lifetronics
Capacity Oil Cooled 3000 KVA
Applications
- Industrial Use – CNC machines, PLCs, VFDs, automation equipment, printing & textile units
- Medical Equipment – MRI, CT scan, X-ray, ECG, diagnostic & OT equipment
- IT & Telecom – Data centers, server rooms, telecom networks
- Commercial Sector – Hotels, malls, educational institutions, and offices
Our Control Panel Services
Technical Specifications:
Technology: IGBT & DSP/PWM based static voltage correction
Input Voltage Range: 170V – 480V (customizable)
Output Voltage: 230V ±1% (Single Phase) / 400V ±1% (Three Phase)
Correction Speed: Within milliseconds (< 20 ms)
Capacity Range: 5 kVA to 500 kVA (custom-built models available)
Efficiency: > 98% (typical)
Cooling System: Natural / Forced Air Cooling
Frequency: 50 Hz ± 5%
Waveform Distortion: Nil (No waveform distortion)
Protection Features:
Over-voltage & under-voltage protection
Overload & short-circuit protection
Surge & spike suppression
Phase reversal and phase loss protection (for 3-phase models)
Display: Digital LED/LCD display for input/output voltage & current
Duty Cycle: 100% continuous
Operating Temperature: 0°C to 45°C
Environment: Indoor use / outdoor with enclosure
Sailent Features
IGBT & DSP Controlled Technology – Advanced electronic design for precise voltage regulation
Ultra-Fast Correction Speed – Response time within milliseconds for sensitive equipment
High Accuracy Output – Maintains constant output voltage ±1%
Maintenance-Free Design – No moving parts, no wear & tear like servo stabilizers
Energy Efficient – More than 98% efficiency with very low power losses
Silent Operation – No mechanical noise during operation
Wide Input Voltage Range – Handles severe fluctuations effectively
Comprehensive Protection – Over-voltage, under-voltage, surge, overload & short-circuit safety
Digital Display Panel – Real-time monitoring of input/output voltage & load
Compact & Lightweight – Easy to install and space-saving design
Continuous Duty Cycle – Suitable for 24×7 operation in industrial & medical environments
Custom-Built Models Available – Tailored capacity & specifications for client needs
Key Features & Purpose
Ultra-Fast Voltage Correction – Response time in milliseconds.
No Moving Parts – Fully electronic design → maintenance-free.
High Accuracy Output Voltage – Typically ±1%.
Energy Efficient – Very low power loss compared to servo models.
Advanced Protection – Against over-voltage, under-voltage, surge, and short circuit.
Compact Design – Space-saving and lightweight.
